10 Advanced WebDriver Tips and Tricks Part 1

As you probably know I am developing a series posts called- Pragmatic Automation with WebDriver. They consist of tons of practical information how to start writing automation tests with WebDriver. Also, contain a lot of more advanced topics such as automation strategies, benchmarks and researches. In the next couple of publications, I am going to share with you some Advanced WebDriver usages in tests. Without further ado, here are the today’s advanced WebDriver Automation tips and trips.

1. Taking a Screenshot

You can use the following method to take a full-screen screenshot of the browser.

public void TakeFullScreenshot(IWebDriver driver, String filename)
{
    Screenshot screenshot = ((ITakesScreenshot)driver).GetScreenshot();
    screenshot.SaveAsFile(filename, ImageFormat.Png);
}

Sometimes you may need to take a screenshot of a single element.

public void TakeScreenshotOfElement(IWebDriver driver, By by, string fileName)
{
    // 1. Make screenshot of all screen
    var screenshotDriver = driver as ITakesScreenshot;
    Screenshot screenshot = screenshotDriver.GetScreenshot();
    var bmpScreen = new Bitmap(new MemoryStream(screenshot.AsByteArray));
    // 2. Get screenshot of specific element
    IWebElement element = driver.FindElement(by);
    var cropArea = new Rectangle(element.Location, element.Size);
    var bitmap = bmpScreen.Clone(cropArea, bmpScreen.PixelFormat);
    bitmap.Save(fileName);
}

First we make a full-screen screenshot then we locate the specified element by its location and size attributes. After that, the found rectangle chunk is saved as a bitmap.

Here is how you use both methods in tests.

public void WebDriverAdvancedUsage_TakingFullScrenenScreenshot()
{
    this.driver.Navigate().GoToUrl(@"http://automatetheplanet.com");
    this.WaitUntilLoaded();
    string tempFilePath = Path.GetTempFileName().Replace(".tmp", ".png");
    this.TakeFullScreenshot(this.driver, tempFilePath);
}

public void WebDriverAdvancedUsage_TakingElementScreenshot()
{
    this.driver.Navigate().GoToUrl(@"http://automatetheplanet.com");
    this.WaitUntilLoaded();
    string tempFilePath = Path.GetTempFileName().Replace(".tmp", ".png");
    this.TakeScreenshotOfElement(this.driver,
    By.XPath("//*[@id='tve_editor']/div[2]/div[2]/div/div"), tempFilePath);
}

We get a temp file name through the special Path .NET class. By default temp files are generated with “.tmp” extension because of that we replace it with “.png”.

2. Get HTML Source of WebElement

You can use the GetAttribute method of the IWebElement interface to get the inner HTML of a specific element.

public void GetHtmlSourceOfWebElement()
{
    this.driver.Navigate().GoToUrl(@"http://automatetheplanet.com");
    this.WaitUntilLoaded();
    var element =
    this.driver.FindElement(By.XPath("//*[@id='tve_editor']/div[2]/div[3]/div/div"));
    string sourceHtml = element.GetAttribute("innerHTML");
    Debug.WriteLine(sourceHtml);
}

While ago when we were working on the first version of the BELLATRIX test automation framework, I did this research and afterward we used many of the tricks in lots of the features of our solution.

3. Execute JavaScript

You can use the interface IJavaScriptExecutor to execute JavaScript through WebDriver.

public void ExecuteJavaScript()
{
    this.driver.Navigate().GoToUrl(@"http://automatetheplanet.com");
    this.WaitUntilLoaded();
    IJavaScriptExecutor js = driver as IJavaScriptExecutor;
    string title = (string)js.ExecuteScript("return document.title");
    Debug.WriteLine(title);
}

This test is going to take the current window’s title via JavaScript and print it to the Debug Output Window.

4. Set Page Load Timeout

There are at least three methods that you can use for the job.

First you can set the default driver’s page load timeout through the WebDriver’s options class.

this.driver.Manage().Timeouts().SetPageLoadTimeout(new TimeSpan(0, 0, 10));

You can wait until the page is completely loaded via JavaScript.

private void WaitUntilLoaded()
{
    WebDriverWait wait = new WebDriverWait(driver, TimeSpan.FromSeconds(30));
    wait.Until((x) =>
    {
        return ((IJavaScriptExecutor)this.driver)
    .ExecuteScript("return document.readyState").Equals("complete");
    });
}

Your third option is to wait for a specific element(s) to be visible on the page.

WebDriverWait wait = new WebDriverWait(driver, TimeSpan.FromSeconds(30));
wait.Until(ExpectedConditions.VisibilityOfAllElementsLocatedBy(
By.XPath("//*[@id='tve_editor']/div[2]/div[2]/div/div")));

5. Execute Tests in a Headless Browser

PhantomJS is a headless WebKit scriptable with a JavaScript API. It has fast and native support for various web standards: DOM handling, CSS selector, JSON, Canvas, and SVG. In order to be able to use the PhantomJSDriver in your code, you first need to download its binaries.

public void ExecuteInHeadlessBrowser()
{
    this.driver = new PhantomJSDriver(
    @"D:ProjectsPatternsInAutomation.TestsWebDriver.Series.TestsDrivers");
    this.driver.Navigate().GoToUrl(@"http://automatetheplanet.com");
    this.WaitUntilLoaded();
    IJavaScriptExecutor js = driver as IJavaScriptExecutor;
    string title = (string)js.ExecuteScript("return document.title");
    Debug.WriteLine(title);
}

This test is executed under 3 seconds through the PhantomJSDriver. Almost three times faster than with the FirefoxDriver.

6. Check If an Element Is Visible

You can use the Displayed property of the IWebElement interface.

public void CheckIfElementIsVisible()
{
    this.driver.Navigate().GoToUrl(@"http://automatetheplanet.com");
    Assert.IsTrue(driver.FindElement(
    By.XPath("//*[@id='tve_editor']/div[2]/div[2]/div/div")).Displayed);
}

7. Use Specific Profile

By default WebDriver always assigns a new ‘clean’ profile if you use the FirefoxDriver’s default constructor. However, sometimes you may want to fine-tune the profile e.g. add extensions, turn off the JavaScript, etc.

FirefoxProfileManager profileManager = new FirefoxProfileManager();
FirefoxProfile profile = profileManager.GetProfile("YourProfileName");
this.driver = new FirefoxDriver(profile);

You can do some similar configurations for the ChromeDriver.

ChromeOptions options = new ChromeOptions();
// set some options
DesiredCapabilities dc = DesiredCapabilities.Chrome();
dc.SetCapability(ChromeOptions.Capability, options);
IWebDriver driver = new RemoteWebDriver(dc);

8. Turn Off JavaScript

You can use the code from point 7 to set up a new Firefox profile. Then you need to set the ‘javascript.enabled’ attribute to false.

FirefoxProfileManager profileManager = new FirefoxProfileManager();
FirefoxProfile profile = profileManager.GetProfile("HARDDISKUSER");
profile.SetPreference("javascript.enabled", false);
this.driver = new FirefoxDriver(profile);

9. Manage Cookies

Before you can work with the cookies of a site, you need to navigate to some of its pages.

Add a New Cookie

Cookie cookie = new Cookie("key", "value");
this.driver.Manage().Cookies.AddCookie(cookie);

Get All Cookies

var cookies = this.driver.Manage().Cookies.AllCookies;
foreach (var currentCookie in cookies)
{
    Debug.WriteLine(currentCookie.Value);
}

Delete a Cookie by Name

this.driver.Manage().Cookies.DeleteCookieNamed("CookieName");

Delete All Cookies

this.driver.Manage().Cookies.DeleteAllCookies();

Get a Cookie by Name

var myCookie = this.driver.Manage().Cookies.GetCookieNamed("CookieName");
Debug.WriteLine(myCookie.Value);

10. Maximize Window

Use the Maximize method of the IWindow interface.

public void MaximizeWindow()
{
    this.driver.Navigate().GoToUrl(@"http://automatetheplanet.com");
    this.driver.Manage().Window.Maximize();
}
