The next article from the mobile test automation series will be dedicated to Appium. All you need to to know – from the most basic operations to the most advanced configurations.
Appium is an open source test automation framework for use with native, hybrid and mobile web apps. It drives iOS, Android, and Windows apps using the WebDriver protocol. It is the “standard” for mobile test automation.
Download Appium C# Cheat Sheet PDF
Initialize
// NuGet: Appium.WebDriver
_appiumLocalService = new AppiumServiceBuilder().UsingAnyFreePort().Build(); // Creates local Appium server instance
_appiumLocalService.Start(); // Starts local Appium server instance
var appiumOptions = new AppiumOptions();
// Android capabilities
appiumOptions.AddAdditionalCapability(MobileCapabilityType.AutomationName, "UiAutomator2");
appiumOptions.AddAdditionalCapability(MobileCapabilityType.DeviceName, "Android Virtual Device");
appiumOptions.AddAdditionalCapability(MobileCapabilityType.PlatformName, "Android");
appiumOptions.AddAdditionalCapability(MobileCapabilityType.PlatformVersion, "7.1");
// iOS capabilities
appiumOptions.AddAdditionalCapability(MobileCapabilityType.AutomationName, "XCUITest");
appiumOptions.AddAdditionalCapability(MobileCapabilityType.DeviceName, "iPhone 11");
appiumOptions.AddAdditionalCapability(MobileCapabilityType.PlatformName, "iOS");
appiumOptions.AddAdditionalCapability(MobileCapabilityType.PlatformVersion, "13.2");
// Install and start an app on Android
appiumOptions.AddAdditionalCapability(AndroidMobileCapabilityType.AppPackage, "com.example.android.apis");
appiumOptions.AddAdditionalCapability(AndroidMobileCapabilityType.AppActivity, ".ApiDemos");
appiumOptions.AddAdditionalCapability(MobileCapabilityType.App, "path/to/TestApp.apk");
// Install and start an app on iOS
appiumOptions.AddAdditionalCapability(MobileCapabilityType.App, "path/to/TestApp.app.zip");
// Start mobile browser on Android
appiumOptions.AddAdditionalCapability(MobileCapabilityType.BrowserName, "Chrome");
// Start mobile browser on iOS
appiumOptions.AddAdditionalCapability(MobileCapabilityType.BrowserName, "safari");
// Set WebView Context for Hybrid Apps
((IContextAware)_driver).Context = ((IContextAware)_driver).Contexts.FirstOrDefault(c => c.Contains("WEBVIEW"));
// Use local server instance
_driver = new AndroidDriver<AndroidElement>(_appiumLocalService, appiumOptions); // initialize Android driver on local server instance
_driver = new IOSDriver<IOSElement>(_appiumLocalService, appiumOptions); // initialize iOS driver on local server instance
// Use remote Appium driver
_driver = new AndroidDriver<AndroidElement>(new Uri("127.0.0.1:4723/wd/hub"), appiumOptions); // initialize Android remote driver
_driver = new IOSDriver<IOSElement>(new Uri("127.0.0.1:4723/wd/hub"), appiumOptions); // initialize iOS remote driverLocators
_driver.FindElementById("android:id/text1");
_driver.FindElementByClassName("android.widget.CheckBox");
_driver.FindElementByXPath("//*[@text='Views']");
_driver.FindElementByAccessibilityId("Views");
_driver.FindElementByImage(base64EncodedImageFile);
_driver.FindElementByAndroidUIAutomator("new UiSelector().text("Views");");
_driver.FindElementByIOSNsPredicate("type == 'XCUIElementBottn' AND name == 'ComputeSumButton'");
// Find multiple elements
_driver.FindElementsByClassName("android.widget.CheckBox");Actions
// Alert handling
_driver.SwitchTo().Alert().Accept()
_driver.SwitchTo().Alert().Dismiss()
// Basic actions;
element.Click();
element.SendKeys("textToType");
element.Clear();
// Change orientation
var rotatable = (IRotatable)_driver;
rotatable.Orientation = ScreenOrientation.Landscape; // Portrait
// Clipboard
_driver.SetClipboardText("1234", "plaintext");
string clipboard = _driver.GetClipboardText();
// Mobile gestures
TouchAction touchAction = new TouchAction(_driver);
touchAction.Tap(x, y, count);
touchAction.Press(x, y);
touchAction.Wait(200);
touchAction.MoveTo(x, y);
touchAction.Release();
touchAction.LongPress(x, y);
touchAction.Perform();
// Simulate phone call (Emulator only)
_driver.MakeGsmCall("5551237890", GsmCallActions.Accept);
_driver.MakeGsmCall("5551237890", GsmCallActions.Call);
_driver.MakeGsmCall("5551237890", GsmCallActions.Cancel);
_driver.MakeGsmCall("5551237890", GsmCallActions.Hold);
// Set GSM voice state (Emulator only)
_driver.SetGsmVoice(GsmVoiceState.Denied);
_driver.SetGsmVoice(GsmVoiceState.Home);
_driver.SetGsmVoice(GsmVoiceState.Off);
_driver.SetGsmVoice(GsmVoiceState.On);
_driver.SetGsmVoice(GsmVoiceState.Roaming);
_driver.SetGsmVoice(GsmVoiceState.Searching);
_driver.SetGsmVoice(GsmVoiceState.Unregistered);
// Set GSM signal strength (Emulator only)
_driver.SetGsmSignalStrength(GsmSignalStrength.Good);
_driver.SetGsmSignalStrength(GsmSignalStrength.Great);
_driver.SetGsmSignalStrength(GsmSignalStrength.Moderate);
_driver.SetGsmSignalStrength(GsmSignalStrength.NoneOrUnknown);
_driver.SetGsmSignalStrength(GsmSignalStrength.Poor);
// Simulate receiving SMS message (Emulator only)
_driver.SendSms("555-555-5555", "Your code is 123456");
// Toggle services
_driver.ToggleAirplaneMode();
_driver.ToggleData();
_driver.ToggleLocationServices();
_driver.ToggleWifi();
// Soft keyboard actions
_driver.IsKeyboardShown(); // returns bool
_driver.HideKeyboard();
// Lock device
_driver.IsLocked(); // returns bool
_driver.Lock();
_driver.Unlock();
// Notifications
_driver.OpenNotifications();
// Geolocation actions
_driver.Location; // returns Location {Latitude, Longitude, Altitude}
_driver.Location.Altitude = 94.23;
_driver.Location.Latitude = 121.21;
_driver.Location.Longitude = 11.56;
// Get system time
_driver.DeviceTime; // returns string
// Get display density
_driver.GetDisplayDensity(); // returns float
// File actions
_driver.PushFile("/data/local/tmp/file", new FileInfo("path/to/file"))
_driver.PullFile("/path/to/device/file"); // returns byte[]
_driver.PullFolder("/path/to/device"); // returns byte[]Advanced Actions
Common
// Multitouch action
TouchAction actionOne = new TouchAction(_driver);
actionOne.Press(10, 10);
actionOne.MoveTo(10, 100);
actionOne.Release();
TouchAction actionTwo = new TouchAction(_driver);
actionTwo.Press(20, 20);
actionTwo.MoveTo(20, 200);
actionTwo.Release();
MultiAction action = new MultiAction(_driver);
action.Add(actionOne);
action.Add(actionTwo);
action.Perform();
// Swipe using touch action
TouchAction touchAction = new TouchAction(_driver);
var element = _driver.FindElementById("android:id/text1");
Point point = element.Coordinates.LocationInDom;
Size size = element.Size;
touchAction
.Press(point.X + 5, point.Y + 5).Wait(200)
.MoveTo(point.X + size.Width - 5, point.Y + size.Height - 5)
.Release().Perform()
// Scroll using IJavaScriptExecutor
var js = (IJavaScriptExecutor)_driver;
var swipe = new Dictionary<string, string>();
swipe.Add("direction", "down"); // "up", "right", "left"
swipe.Add("element", element.Id);
js.ExecuteScript("mobile:swipe", swipe);
// Scroll element into veiw by Android UI automator
_driver.FindElementByAndroidUIAutomator(
"new UiScrollable(new UiSelector()).scrollIntoView(new UiSelector().text("Views"));");
// Update Device Settings
_driver.SetSetting("sample", "value");
_driver.Settings // Dictionary<string, object> propertyAndroid
// Add photos
driver.PushFile("/mnt/sdcard/Pictures/img.jpg", new FileInfo("path/to/img.jpg"))
// Simulate hardware key
_driver.PressKeyCode(new KeyEvent(AndroidKeyCode.Home));
_driver.LongPressKeyCode(new KeyEvent(AndroidKeyCode.Keycode_POWER));
// Get current battery percentage
_driver.ExecuteScript("mobile: shell", "{"command": "dumpsys", "args": ["battery"]}").ToString();
// Set battery percentage
_driver.ExecuteScript("mobile: shell", "{"command": "dumpsys", "args": ["battery", "set", "level", "100"]}").ToString();
// Reset battery percentage
_driver.ExecuteScript("mobile: shell", "{"command": "dumpsys", "args": ["battery", "reset"]}").ToString();
// Take screenshot
_driver.GetScreenshot(); // returns Screenshot (base64 encoded PNG)
// Screen record
_driver.StartRecordingScreen(
AndroidStartScreenRecordingOptions.GetAndroidStartScreenRecordingOptions()
.WithTimeLimit(TimeSpan.FromSeconds(10))
.WithBitRate(500000)
.WithVideoSize("720x1280"));
_driver.StopRecordingScreen();iOS
// Add photos
driver.PushFile("img.jpg", new FileInfo("path/to/img.jpg"))
// Simulate hardware key
var args = new Dictionary<string, string>();
args.Add("name", "home"); // volumeup; volumedown
_driver.ExecuteScript("mobile: pressButton", args);
// Sending voice commands to Siri
var args = new Dictionary<string, string>();
args.Add("text", "Hey Siri, what's happening?");
_driver.ExecuteScript("mobile: siriCommand", args);
// Perform Touch ID in iOS Simulator
_driver.PerformTouchID(false); // Simulates a failed touch ID
_driver.PerformTouchID(true); // Simulates a passing touch ID
// Shake device
_driver.ShakeDevice();Application Management
Android
// Install app
_driver.InstallApp("path/to/app.apk");
// Remove app
_driver.RemoveApp("com.example.AppName");
// Verify app is installed
_driver.IsAppInstalled("com.example.android.apis"); // returns bool
// Launch app
_driver.LaunchApp();
// Start activity
_driver.StartActivity("com.example.android.apis", ".ApiDemos");
// Start activity with intent
_driver.StartActivityWithIntent("com.example.android.apis", ".ApiDemos", "intentAction");
// Get current activity
_driver.CurrentActivity; // string property
// Get current package
_driver.CurrentPackage; // string property
// Reset app
_driver.ResetApp();
// Close app
_driver.CloseApp();
// Run current app in background
_driver.BackgroundApp(10); // 10 seconds
// Terminate app
_driver.TerminateApp("com.example.android.apis"); // returns bool
// Check app's current state
_driver.GetAppState("com.example.android.apis"); // returns AppState
// Get app strings
_driver.GetAppStringDictionary("en", "/path/to/file"); // returns Dictionary<string, object>iOS
// Install app
var args = new Dictionary<string, string>();
args.Add("app", "path/to/app.ipa");
_driver.ExecuteScript("mobile: installApp", args);
// Remove app
var args = new Dictionary<string, string>();
args.Add("bundleId", "com.myapp");
_driver.ExecuteScript("mobile: removeApp", args);
// Verify app is installed
var args = new Dictionary<string, string>();
args.Add("bundleId", "com.myapp");
(bool)_driver.ExecuteScript("mobile: isAppInstalled", args);
// Launch app
var args = new Dictionary<string, string>();
args.Add("bundleId", "com.apple.calculator");
_driver.ExecuteScript("mobile: launchApp", args);
// Switch app to foreground
var args = new Dictionary<string, string>();
args.Add("bundleId", "com.myapp");
_driver.ExecuteScript("mobile: activateApp", args);
// Terminate app
var args = new Dictionary<string, string>();
args.Add("bundleId", "com.myapp");
// will return false if app is not running, otherwise true
(bool)_driver.ExecuteScript("mobile: terminateApp", args);
// Check app's current state
var args = new Dictionary<string, string>();
args.Add("bundleId", "com.myapp");
(AppState)_driver.ExecuteScript("mobile: queryAppState", args);
