The next article from the mobile test automation series will be dedicated to the ADB. All you need to to know- the most basic operations to the most advanced configurations.
ADB, Android Debug Bridge, is a command-line utility included with Google’s Android SDK. ADB can control your device over USB from a computer, copy files back and forth, install and uninstall apps, run shell commands, and more.
While ago when we were working on the first version of the BELLATRIX test automation framework, I did this research while I was working on a similar features for our solution.
ADB Basics
adb devices (lists connected devices)
adb root (restarts adbd with root permissions)
adb start-server (starts the adb server)
adb kill-server (kills the adb server)
adb reboot (reboots the device)
adb devices -l (list of devices by product/model)
adb shell (starts the backround terminal)
exit (exits the background terminal)
adb help (list all commands)
adb -s <deviceName> <command> (redirect command to specific device)
adb –d <command> (directs command to only attached USB device)
adb –e <command> (directs command to only attached emulator)Package Installation
adb shell install <apk> (install app)
adb shell install <path> (install app from phone path)
adb shell install -r <path> (install app from phone path)
adb shell uninstall <name> (remove the app)Paths
/data/data/<package>/databases (app databases)
/data/data/<package>/shared_prefs/ (shared preferences)
/data/app (apk installed by user)
/system/app (pre-installed APK files)
/mmt/asec (encrypted apps) (App2SD)
/mmt/emmc (internal SD Card)
/mmt/adcard (external/Internal SD Card)
/mmt/adcard/external_sd (external SD Card)
adb shell ls (list directory contents)
adb shell ls -s (print size of each file)
adb shell ls -R (list subdirectories recursively)File Operations
adb push <local> <remote> (copy file/dir to device)
adb pull <remote> <local> (copy file/dir from device)
run-as <package> cat <file> (access the private package files)Phone Info
adb get-statе (print device state)
adb get-serialno (get the serial number)
adb shell dumpsys iphonesybinfo (get the IMEI)
adb shell netstat (list TCP connectivity)
adb shell pwd (print current working directory)
adb shell dumpsys battery (battery status)
adb shell pm list features (list phone features)
adb shell service list (list all services)
adb shell dumpsys activity <package>/<activity> (activity info)
adb shell ps (print process status)
adb shell wm size (displays the current screen resolution)
dumpsys window windows | grep -E 'mCurrentFocus|mFocusedApp' (print current app's opened activity)Package Info
adb shell list packages (list package names)
adb shell list packages -r (list package name + path to apks)
adb shell list packages -3 (list third party package names)
adb shell list packages -s (list only system packages)
adb shell list packages -u (list package names + uninstalled)
adb shell dumpsys package packages (list info on all apps)
adb shell dump <name> (list info on one package)
adb shell path <package> (path to the apk file)Configure Settings Commands
adb shell dumpsys battery set level <n> (change the level from 0 to 100)
adb shell dumpsys battery set status<n> (change the level to unknown, charging, discharging, not charging or full)
adb shell dumpsys battery reset (reset the battery)
adb shell dumpsys battery set usb <n> (change the status of USB connection. ON or OFF)
adb shell wm size WxH (sets the resolution to WxH)Device Related Commands
adb reboot-recovery (reboot device into recovery mode)
adb reboot fastboot (reboot device into recovery mode)
adb shell screencap -p "/path/to/screenshot.png" (capture screenshot)
adb shell screenrecord "/path/to/record.mp4" (record device screen)
adb backup -apk -all -f backup.ab (backup settings and apps)
adb backup -apk -shared -all -f backup.ab (backup settings, apps and shared storage)
adb backup -apk -nosystem -all -f backup.ab (backup only non-system apps)
adb restore backup.ab (restore a previous backup)
adb shell am start|startservice|broadcast <INTENT>[<COMPONENT>]
-a <ACTION> e.g. android.intent.action.VIEW
-c <CATEGORY> e.g. android.intent.category.LAUNCHER (start activity intent)
adb shell am start -a android.intent.action.VIEW -d URL (open URL)
adb shell am start -t image/* -a android.intent.action.VIEW (opens gallery)Logs
adb logcat (view device log)
adb bugreport (print bug reports)Permissions
adb shell permissions groups (list permission groups definitions)
adb shell list permissions -g -r (list permissions details)
